Gigabyte Z490 UD AC DDR4 10th Gen Intel LGA1200 Socket Mainboard

Add to wishlistAdded to wishlistRemoved from wishlist 0

Let’s check the overview

  • Model: Gigabyte Z490 UD AC
  • Chipset: Intel Z490 Express
  • Intel Socket LGA1200 for 10th Gen Processors
  • 4 x DIMM, Max. 128GB DDR4
  • CrossFire Supported

৳ 20,400 ৳ 17,480

🗣️ প্রোডাক্ট অর্ডারের পূর্বে অবশ্যই সাপোর্ট থেকে স্টক এবং ডেলিভারি সম্পর্কে জেনে অর্ডার করুন"
🗣️ গ্রান্ড ওপেনিং অফার এর প্রোডাক্ট cash on delivery তে অর্ডার করে IDB Bhaban Branch থেকে কালেক্ট করুন


📢 অর্ডারের জন্য যোগাযোগ করুন
🤙 01912-905635
📱 01886905635
📱 01886905636

gigabyte-z490-ud-ac-mainboard

About This Product

gigabyte-z490-ud-ac-mainboard : Model – Gigabyte Z490 UD AC, CPU Sockets – LGA1200, Chipset – Intel Z490 Express, Supported CPU – 10th Generation Intel Core i9/ i7/ i5/ i3/ Pentium/ Celeron Processors, Generation – 10th, Memory Type – DDR4, Memory MHz – Intel Core i9/i7 (4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2933 / 2800 / 2666 / 2400 / 2133MHz), Intel Core i5/i3/Pentium/Celeron (2666/2400/2133MHz), Memory Channel – Dual channel, Memory Slot – 4, Memory Max. – 128GB, Optane Memory Support – Yes, Graphic – Integrated Graphics, Multi-GPU Support – AMD Quad-GPU CrossFire and 2-Way AMD CrossFire, PCI Express Slot – 1 x PCI Express x16 slot, running at x16, 1 x PCI Express x16 slot, running at x4, 3 x PCI Express x1 slots, Special Features – Dual Channel Non-ECC Unbuffered DDR4, 4 DIMM, Intel Optane Memory Ready, Direct 11+1 Phases Digital VRM Solution with Low RDS(on) MOSFETs, Enlarged VRM

Heatsink with Increased Surface Contact Air-Flow Grooving, GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management, Multi-Way Graphics Support with PCIe Armor and Ultra Durable Design, Dual Ultra-Fast M.2 with PCIe Gen3 X4 & One Supports SATA Protocol, Intel Native USB 3.2 Gen2 Type-A with Speed Up To 10Gbps, RGB FUSION 2.0 Support Addressable LED & RGB LED Strips, Smart Fan 5 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP, Q-Flash Plus Updates BIOS without Installing the CPU, Memory and Graphics Card, Rear IO Armor with Pre-Installed I/O Shield, CEC 2019 Ready, Save the Power as Easy as One Click, Lightning-Fast Intel Thunderbolt 3 AIC Support, Others – 1 x 24-pin ATX main power connector, 1 x 4-pin.

ATX 12V power connector, 1 x 8-pin ATX 12V power connector, 1 x CPU fan header, 4 x system fan headers, 2 x addressable LED strip headers, 1 x Q-Flash Plus button, 1 x front panel header, 1 x front panel audio header, 1 x S/PDIF Out header, 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only), 2 x Thunderbolt add-in card connectors, 1 x serial port header, 1 x Clear CMOS jumper, 1 x PS/2 keyboard/mouse port, 2 x SMA antenna connectors (1T1R), 1 x RJ-45 port, 3 x audio jacks, Wireless Communication module: Intel Wi-Fi AC 9462, BLUETOOTH 5, Warranty – 3 Year, Country of Origin – Taiwan, Made in/ Assemble – China.

Specification

Basic Information
Supported CPU Support for 10th Generation Intel Core i9 processors/Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1200 package
Chipset Intel Z490 Express Chipset
BIOS 1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor ATX Form Factor; 30.5cm x 24.4cm
Expansion Slots
PCI 1 x PCI Express x16 slot, running at x16 (PCIEX16)
1 x PCI Express x16 slot, running at x4 (PCIEX4)
3 x PCI Express x1 slots
M.2 Socket 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2A_SB)
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 PCIe x4/x2 SSD support) (M2M_SB)
Memory
Type Dual channel memory architecture
Slots 4 x DDR4 DIMM
Supported Memory Intel Core i9/i7 processors:
Support for DDR4 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2933 / 2800 / 2666 / 2400 / 2133 MHz memory modules
Intel Core i5/ i3/ Pentium/ Celeron processors:
Support for DDR4 2666/ 2400/ 2133 MHz memory modules
Maximum Mamory 128 GB
Graphics
Graphics Integrated Graphics Processor-Intel HD Graphics support:
1 x HDMI port, supporting a maximum resolution of 4096×2160@30 Hz
Max Shared Memory 512MB
Connector & Ports
HDMI 1 x HDMI port, supporting a maximum resolution of 4096×2160@30 Hz
USB (s) 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
7 x USB 3.2 Gen 1 ports (5 ports on the back panel, 2 ports available through the internal USB header)
4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
LAN Port (s) Realtek GbE LAN chip (1000 Mbit/100 Mbit)
Intel Wi-Fi AC 9462:
Intel CNVi interface 802.11a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band
BLUETOOTH 5
Support for 1×1 11ac wireless standard and up to 433 Mbps data rate
Supported Storage 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2A_SB)
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 PCIe x4/x2 SSD support) (M2M_SB)
6 x SATA 6Gb/s connectors
Support for RAID 0, RAID 1, RAID 5, and RAID 10
Intel Optane Memory Ready
Audio Realtek ALC887 codec
High Definition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
Internal I/O Ports 1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
4 x system fan headers
2 x addressable LED strip headers
2 x RGB LED strip headers
1 x Q-Flash Plus button
6 x SATA 6Gb/s connectors
2 x M.2 Socket 3 connectors
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
2 x Thunderbolt add-in card connectors
1 x serial port header
1 x Clear CMOS jumper
Warranty Information
Manufacturing Warranty 03 Years
Others
Special Features Support for APP Center
@BIOS
EasyTune
Fast Boot
Game Boost
ON/OFF Charge
RGB Fusion
Smart Backup
System Information Viewer
Support for Q-Flash Plus
Support for Q-Flash
Support for Xpress Install
